39" Matte Black Tile Insert Linear Shower Drain with Hair Trap | SereneDrains

39 Inch Matte Black Tile Insert Linear Shower Drain with Free Hair Trap, Curbless Walk-In Design | SereneDrains

The SereneDrains 39-Inch Matte Black Tile Insert Linear Shower Drain is engineered to blend seamlessly with your bathroom floor. Designed to camouflage into your layout, your chosen shower tile extends directly over the drain tray to create a nearly invisible, flush-mounted, and ultra-minimalist appearance. Perfect for modern luxury bathrooms, curbless walk-in showers, and barrier-free wetrooms.

Dimensions & Sizing

• Net Size (Channel Length): 39 3/8" x 2 3/4" (1000mm)
• Overall Size (With Flange): 40.95" x 4 3/8"
• Channel Width: 2 3/4" (70 mm)
• Intake Area: 21.12 sq. in.
• Tile Compatibility: Fits tiles up to 10mm deep (14mm lip). Perfectly sized to match standard 1/2", 1", 2", and 4" tiles without awkward cuts.
• Also available in: 16", 24", 30", 35", 47", and 59" lengths.

Premium Technical Specifications

• Material Construction: Heavy-duty, 16-gauge 304 stainless steel (flange, channel body, and tile-in grate cover) for maximum corrosion and rust resistance.
• No Plastic Parts: 100% premium metal construction throughout.
• Finishing: Premium laser-cut electropolish matte black finish.
• Structural Integrity: Rounded, folded frame edges (not welded) provide twice the structural strength and a smooth touch underfoot.
• Leak Protection: All bodies are fully welded and strict leak-tested before dispatch.
• Plumbing Outlet: 2-inch diameter central vertical outlet. Designed to install effortlessly into any standard 2" shower drain flange.
• High-Capacity Flow Rate:
  • At shower entrance: 6.3 GPM (0.4 l/s)
  • Against the wall: 9.5 GPM (0.6 l/s)

Versatile Applications & Universal Waterproofing

This architectural linear drain is ideal for residential and high-end commercial projects, including showers, baths, kitchens, balconies, luxury hotels, spas, and commercial gyms. Its flush-mount profile is fully ADA compliant for wheelchair access and barrier-free, curbless walk-in floor plans.

Multi-System Waterproofing Compatibility

Built with an integrated flange body edge, it allows the drain to sit directly on the floor edge without unstable leveling feet, providing rock-solid stability. It is fully compatible with all industry-standard waterproofing methods:

• Hot-Mop systems
• Liquid/Painted membranes
• Sheet membranes
• Vinyl waterproofing

Key Features & What's Included

Why Choose SereneDrains?

• Pre-Sloped Channel: Ensures fast, efficient water drainage toward the center outlet to prevent pooling.
• Easy Maintenance: The removable tile tray allows for hassle-free cleaning. Simply lift to access the internal plumbing.
• Complete Kit: Everything you need for a professional installation right out of the box.

Package Includes:

• 16-Gauge 304 Stainless Steel Channel Body & Grate

• Debris Strainer / Easy-Clean Hair Trap
• Metal Grate Puller Key
• Waterproofing Membrane Sheet (Optional wrap around the flange)
• Installation Instructions

Shipping, Returns & Support

• Availability: In Stock & Ready to Ship.
• Shipping: Free Standard Shipping included.
• Guarantee: 30-day return policy.
• Looking for matching plumbing parts and accessories for drains ? We offer premium ABS, PVC, and Cast Iron flanges, along with replacement parts.
• Contractors and Designers: Contact us directly for bulk orders and quantity commercial discounts.
